2015 MARVEL SERIES 8 MARK III Vertical Tilt-Frame Band Saw #8362

2015 MARVEL SERIES 8 MARK III VERTICAL TILT-FRAME BAND SAW #8362

SPECIFICATIONS:
• Manufacturer: Marvel Manufacturing / Amada
• Model: Series 8 Mark III / VT4555M
• Year: 2015
• Type: Vertical Tilt-Frame Metal-Cutting Band Saw

CUTTING CAPACITY:
• 90° Capacity: 18" H x 22" V
• Round Capacity at 90°: 18"
• 45° Right: 18" H x 14.5" V
• 45° Left: 18" H x 13" V
• 60° Right: 18" H x 9.7" V
• 60° Left: 18" H x 7.3" V
• Miter/Tilt Range: 0°–60° Left and Right

BLADE:
• Blade Length: 15' 4" (184")
• Blade Width: 1.25"
• Blade Thickness: 0.042"
• Blade Speed: 50–450 FPM, Variable

MOTOR:
• Main Motor: 5 HP

TABLE:
• Table Size: 24.25" x 33"
• Table Height: 34.5"

OTHER SPECIFICATIONS:
• Blade Feed Pressure: 0–250 lb, Variable
• Wheel Diameter: 19"
• Column: 3° Forward Cant
• Coolant System: Flood Coolant
• Automatic Column Return
• Blade Break/Stall Detection
• Cast-Iron Construction
• Mechanical Drive
