2012 GMC 21" x 80" Gap Bed Engine Lathe 3 1/8" Spindle DRO Taper #7689 #1

2012 GMC 21" x 80" Gap Bed Engine Lathe 3 1/8" Spindle Bore DRO Taper Attach. #7689 #1

Specifications:
Model: GML-2180
Size: 21" x 80"
Swing over bed: 21"
Distance between centers: 80"
Max swing over cross-slide: 13"
Max swing in gap: 25"
Width of bed: 13"
Effective length in gap to spindle: 8"
Effective length in gap to chuck jaw: 6"
Spindle hole dia.: 3-1/8"
Spindle: D1-8 Camlok
Taper of spindle center: MT #6
Spindle speeds ( 15 ): 26 - 1800 RPM
Longitudinal feeds: 0.0027 - 0.15 IPR, 66 kinds
Cross feeds: 0.0013 - 0.075 IPR, 66 kinds

Threads Details
Inch threads: 1 - 56 TPI 66 kinds
Metric threads: 0.5 - 28 mm , 66 kinds
Diamentral pitch threads: 56 - 8 DP , 33 kinds
Module threads: 0.5 - 3.5 MM , 33 kinds

Carriage Details
Maximum travel of top slide: 5"
Maximum travel of cross-slide: 13"
Longitudinal rapid traverse: 18 ft / Min

Tailstock Details:
Diameter of tailstock quill: 2-1/2"
Maximum travel of tailstock quill: 5"
Taper of tailstock quill center: M.T. # 5

Motors Details:
Main motor: ( Pre-wired 220 V / 3 ) 10 HP, 220/440 V, 3 phase
Rapid traverse motor: 1/3 HP, 220/440 V, 3 phase
Coolant pump motor: ( Pre-wired 220 V / 3 ) 1/8 HP, 220/440 V, 3 phase
Machine net weight: 6,650 lbs
Overall dimensions: L x W x H 137" x 46" x 71"
