BRIDGEPORT EZ TRAK SX 2 AXIS CNC / MANUAL TOOLROOM MILLING MACHNE 9" X 48" #5846

BRIDGEPORT EZ TRAK SX 2 AXIS CNC / MANUAL TOOLROOM MILLING MACHNE 9" X 48" #5846

Serial Number BR261439E

CNC or Manual Operation. 2 Axis CNC with 3 Axis readout ( x, y, and quill)

SPECIFICATIONS:

Capacity 9" x 48"

Table Size 9" x 48"

Longitudinal Travel 30"

Cross Travel 12"

Vertical Knee Travel 16"

Spindle Speeds (Variable) 60-4200 RPM

Spindle Taper R-8

Spindle Quill Travel 5"

Positioning Speed (X-Y Axis) 100 IPM

Feed Rate (X-Y Axis, Variable) 0.1-100 IPM

Spindle Quill Feeds (3) 0.0015" - 0.003" - 0.006"

Ram Travel 12"

Distance, Table To Spindle Nose 2 1/2" - 18 1/4"

Throat Distance 6 3/4" - 18 3/4"

Weight 2300 Lbs.

Equipped With:

EZ Trax SX 2 Axis CNC Control

Z Axis Digital Readout System

Bijur Spray Mist Coolant System

Auto-Lube System

Chrome Ways

Work Light

2 H.P. Motor
