Southwestern TRAK 2op Portable Vertical Machining Center Mini Mill #5840

Southwestern TRAK 2op Portable Vertical Machining Center Mini Mill #5840

Pomona, CA

orCall 909-348-5610

Description

Used 2012 Southwestern Trak 2OP Mill Machining Center in good condition. Here is some information from Southwestern:


  • TRAK 2op Features:ProtoTRAK TMX CNC
  • 8 station tool changer
  • X, Y, Z travels: 14” x 12” x 17″
  • Footprint of 2.5′ x 4′
  • Portable and ships with a pallet jack
  • Integrated Jergens™ Ball Lock system
  • Simple conversational programming
  • BT30 spindle taper
  • 3 HP spindle
  • 3-axis simultaneous interpolation
  • Electronic handwheel
  • G code compatible
  • Automatic fixture offsets
  • Indexer compatible


Machine W x D x H (with head all the way up) – 30.5” x 52” x 101

Min height to fit through doorway – 92”

Table size – 18” x 15”

Number of tee slots and pitch – 4 @ 63 mm

Tee slot width – 0.630” or 16 mm

Max table load – 500 lbs.

Ball Lock ® hold down force – 2250 lbs. @ 35 in/lbs. of torque

Machine Net/Shipping lbs. – 2825/3175

X, Y, Z Travels – 14” x 12” x 17”

Max distance from spindle nose table surface – 20.25”

Min distance from spindle nose table surface – 2.75”

Max swing clearance from spindle center to column – 14”

Max Rapid speed X, Y & Z-axis, inches per minute – 600

Tool holder type – BT30

Spindle nose diameter – 2.2” or 56 mm

Max RPM – 6000

Horsepower – 3HP

ATC Tool Capacity – 8

Max tool Diameter – 2”

Retention Knob – BT30

Air Pressure/CFM – 90 psi, 2.5 at 90 psi

Specifications

ManufacturerSouthwestern
ModelTrak 2op
Year2012
ConditionUsed
Serial Number123DQ449427
Stock Number5840
