Okada 5 Axis CNC Gantry Router Machining Center #5834

Okada 5 Axis CNC Gantry Router Machining Center #5834

Pomona, CA

orCall 909-348-5610

Description

Okada Model MM 3024 Model Master 5-Axis CNC Gantry Router

Year 1995

Serial 95324


From composite making company that is closing this facility. Still under power and available for inspection, Los Angeles area.

118” X 78” Table (T-Slotted)

4,400 Lb. Maximum Table Load

31” Distance >From Floor To Table Surface

66”X-Axis Travel

124” Y-Axis Travel

48” Z-Axis Travel

0.0394 – 275 IPM X, Y, Z Cutting Feed Rate

394 IPM Rapid X, Y Feed Rate

315 IPM Rapid Z Feed Rate

96” Distance Between Columns

84” Maximum Height Under Cross Rail

200 – 10,000 Rpm Spindle Speeds

7.5 HP Spindle Motor

BT 40 Spindle Nose Taper

10.83” - 50.23” Spindle Head To Table Surface

0 – 190 Degree Spindle Unit Revolutions Direction

+ Or – 110 Degree Spindle Unit Swinging Direction

Complete With

Fanuc 15mb CNC Control, Full Enclosure

And Glass Scales On All Linear Axes

T-Slotted Table

Way Covers

Specifications

ManufacturerOkada
ModelMM3024
ConditionUsed
Serial Number95324
Stock Number5834
