Chevalier Model FM-3VS Vertical Milling Machine 9" x 42" Table

Chevalier Model FM-3VS Vertical Milling Machine 9" x 42" Table

Pomona, CA

orCall 909-348-5610

Description

Make: Chevalier

Model: FM-3VS

S/N : BM83C699


Chevalier Model FM-3VS Vertical Milling Machine


SPECIFICATIONS

Table Size (in.) 9 x 42

Table Travel (in. – X-axis) 24

Cross Travel (in. – Y-axis) 12

Knee Travel (in. – Z-axis) 16

Ram Travel (in.) 12

Spindle Taper R-8

Number of Spindle Speeds Variable Speed Drive

Range of Spindle Speeds (RPM) 60 – 4,500

Downfeeds of Spindle (in./per/rev.) 0.0015, 0.003, 0.006

Head Overarm Swivel 360°

Head Swivel (R & L) 90°

Head Swivel (F & B) +45° / -38°

Spindle Travel (in.) 5

Spindle Nose to Table (in./min.) 2-3/4

Spindle Nose to Table (in./max.) 18-3/4

Spindle Centerline to Column Surface (in./min.) 2-3/4

Spindle Centerline to Column Surface (in./max.) 18-3/4

T-Slot Number & Size (in.) 3 and 5/8

Work Piece Weight (lbs./max.) 750

Motor 3 HP,

220V/440V/3 Phase/60 Hz.

Floor Dimensions (in./L x W x H) 86-1/2 x 63 x 82-5/8

Weight: 2500 lbs.


Equipped With:

Sony LH30 Millman Digital Readout

X Axis Servo Power Feed

6" Mill Vise

Way Covers

One Shot Lube

Variable Speed Head

Specifications

ManufacturerChevalier
ModelFM-3VS
ConditionUsed
Serial NumberBM83C699
Stock Number5795
