Charmilles Model Robofil 200 5 Axis Wire EDM #5777

Charmilles Model Robofil 200 5 Axis Wire EDM #5777

Pomona, CA

orCall 909-348-5610

Description

Make: Charmilles

Model: Robofil 200 Wire EDM

Year: 1991

S/N 26062



Maximum Workpiece Weight: 1100 Lbs

Machining Stroke ( X x Y x Z ): 12.52" x 8.58" x 5.3"

Maximum Workpiece Dimensions: 35.43" x 20.47" x 5.90"

U / V Travel: +/- 50mm, +/- 50mm

Taper Angle: 0 - 30 Degrees

Standard Wire Diameter : 0.004" to 0.010"

Approximate Overall Dimensions: 145"LR x 99"FB x 88"H

Approximate Machine Weight: 4, 700 Lbs


Equipped With:


Automatic Wire Threading

Submerged Machining

3.5" Floppy Drives

RS232 Communications Capability

Remcor Electric Chiller

Complete Filtration and Dialectric System

Specifications

ManufacturerCharmilles
ModelRobofil 200
ConditionUsed
Serial Number26062
Stock Number5777
