Southwestern Industries Proto Trak TRM 2 Axis CNC Bed Mill #5719

Southwestern Industries Proto Trak TRM 2 Axis CNC Bed Mill #5719

Pomona, CA

orCall 909-348-5610

Description

SOUTHWESTERN INDUSTRIES TRAK TRM 2--AXIS CNC BED MILL

Serial # : 92-132


EQUIPPED WITH: Trak MX2 CNC Controls, Power Draw Bar,  RS232 Port


SPECIFICATIONS:

Table Size               10" x 50"

Travels

     X - Axis 31"

     Y - Axis 17"

     Z - Axis 25"

Quill Diameter  3-15/16"

Spindle Taper 40 NST/NMTBA

Spindle Speeds (Variable)         70-4200 RPM

Spindle Center to Column Face             17.3"

Max. Quill Travel 5"

Quill Feed Per Rev. in Auto Feed 0.002, 0.004, 0.006 IPR

Max. Weight on Work Table 1,320 Lbs.

Drilling Mild Steel 1.5"

Tapping Capacity 1.25"

Milling Capacity 3" Cubed/Min

Boring Capacity 4.75"

Motor: 3 HP, 3 Phase, 220 Volt

Approximate Dimensions 70" x 72" 89"

Approximate Weight 4,500 Lbs.

Specifications

ManufacturerSouthwestern Industries
ModelTRM
ConditionUsed
Serial Number92-132
Stock Number5719
