MARCHANT 4A PNEUMATIC SHRINKER & STRETCHER MACHINE

MARCHANT SHRINKER and STRETCHER MACHINE

Model 4A, PNEUMATIC POWER

SPECIFICATIONS:

CAPACITY:

Tensile Strength 70,000 lbs.

Aluminum Alloy 24ST, ¼" thick x 1½" width

Aluminum Alloy 24SO, 5/16" thick x 2" width

Stainless Steel 3/16" thick x 1½" width

Titanium 5/32" thick x 1" width

THROAT DEPTH: Front of Jaws 4"

STROKE OF RAM ¼"

ADJUSTABLE OPEN HEIGHT

PNEUMATIC ACTUATED By Foot Control

(Pendulum Motion)

AIR PRESSURE REQUIRED 90 – 125 psi

Dimensions 2′ x 2′ Overall Height 57" Approx. Weight 575 lbs.
