6" x 4" x 1/2", MUBEA, 71 TON, 6" X 3/4" SHEAR, 7/8" THRU 7/8" PUNCH Our stock number: 5554

Manufacturer: Mubea Model: KBL 1 1/2 Mechanical Ironworker SPECIFICATIONS: Plate Shear Slitting: 5/8" Plate Shear Trimming: 3/4" Flat Bar: 6" x 3/4" Trim Leg of Angles: 4" x 5/8" Length of Knife: 10 1/4" Section Shear Max. Shear Cross Section Area (sq. in.): 5.2" Angles, Square: 5 x 1/2" Angle up to 45 Dg. Mitre: 4 x 7/16" Unequal Squares: 6 x 4 x 1/2" Tees, Square: 5 x 1/2" Bar Shear Max. Shearing Cross Section (sq. in.): 2.64" Round Bars: 1 3/4" Square Bars: 1 5/8" Coper-Notcher ( Rectangular Tools) Plates: 9/16" Angles, up to root, one stroke: 3 1/2" x 7/16" Tees in Flange up to root, one stroke: 3 1/2" x 7/16" Channels in Flange: 6-8" Beams in Flange: 5-8" Coping Width: 2 1/8" Coping Depth, one stroke: 3 1/8" Coping Depth, repeated: 3 1/2" Coper Notcher ( Triangular Tools) Plates: 9/16" Angles: 3 1/2" x 7/16" Tees in Flange: 3 1/2" x 7/16" Channels in Flange: 6-8" Beams in Flange: 5-8" Notching Depth: 2 3/4" Punch' Pressure: 71 Tons Length of Stroke: 1 1/4" Hole Capacity: 1 1/16 thru 3/4" or 7/8" thru 7/8" Channels in Flange: 4-15" Channels in Web: 3-18" Beams in Web: 3-24" Depth of Throat: 19 5/8" General Number of Strokes Plate Shear: 46 per min. Number of Strokes Section Shear: 40 per min. Number of Strokes Punch: 46 per min. Motor: 7.5 HP Motor Speed: 1700 Rpm Dimensions: 79" x 33" x 70" H Weight: 6830 lbs.
