2018 MAKINO A40 CNC HORIZONTAL MACHINING CENTER

Pomona, CA

orCall 909-348-5610

Description

Manufacturer: Makino Model: A40 CNC Horizontal Machining Center Year: 2018 SPECIFICATIONS: Pallet Size: 15.75" x 15.75" Travels: X Axis-22", Y Axis-25.2", Z Axis, 25.2" B Axis: 360 dg. Indexing Increment (0.001dg) Spindle RPM: 12,000 Rpm Spindle Taper: CAT 40 (HSK-A63 Opt.) Rapid Traverse: 2.362 ipm Cutting Feedrate: 2,362 ipm Maximum Workpiece: 24.8" dia. x 35.4" Maximum Payload: 880 lbs. ATC Capacity: 40 Tool to Tool: 0.9 secs Chip to Chip 2.2 secs Max. Tool Length: 14.2" Max. Tool Weight: 17.6 lbs. Spindle Acceleration 0-12,000 rpm: 0.5 sec Rigid Tapping Sync Speed: 6000 rpm

Specifications

ManufacturerMAKINO
ModelA40 CNC HORIZONTAL MACHINING CENTER
Year2018
ConditionUsed
Serial Number276
Stock Number5593
