Jet JHS-2200A Hydraulic Stacker #5875

Jet JHS-2200A Hydraulic Stacker #5875

Pomona, CA

orCall 909-348-5610

Description

Model number ............................................................................................................................... JHS-2200A

Stock number ...................................................................................................................................... 140531

Capacities and forces: Load capacity ....................................................................................................................... 2200lb (998kg)

Pallet capacity .................................................................................................. 48” x 40” (1219 x 1016mm)

Load center ............................................................................................................................. 20” (508mm)

Maximum lift height ............................................................................................................... 62” (1575mm)

Minimum fork height .............................................................................................................. 2-3/4” (70mm) Handle force required at maximum load ................................................................................... 85 lb (39kg)

Turning radius ............................................................................................................... 360°/50” (1270mm)

Handle strokes to maximum height (no load / max. load) ................................................................ 44 / 86

Foot pedal strokes to maximum height (no load / max. load) ........................................................... 30 / 60

Dimensions: Fork size ........................................................................... 42”L x 5-1/4”W x 2-1/4”H (1067 x 133 x 57mm) Overall fork width (min./max.) .......................................................................... 11” / 27-1/2” (279 / 700mm)

Outrigger width .......................................................................................................................... 4” (102mm) Outrigger height .................................................................................................................... 3-1/2” (90mm) Outrigger inside width (min./max.) ........................................................... 34-1/4” / 50-1/2” (870 / 1283mm)

Outrigger outside width (min./max.) ................................................................... 42” / 58-3/4” (1067 / 1492)

Stacker overall size ............................................................. 62”L x 42”W x 78”H (1575 x 1067 x 1981mm)

Wheels: Load wheel material and size ................................................ Black nylon / 5”OD x 3-1/4”W (127 x 83mm) Caster material and size .........................................................Poly/Aluminum / 7”OD x 2”W (178 x 51mm)

Caster locks ............................................................................................................................................yes

Net weight ................................................................................................................................ 528 lb (240kg)

Shipping weight ........................................................................................................................ 558 lb (253kg)

Specifications

ManufacturerJet
ModelJHS-2200A
ConditionUsed
Serial Number12030068
Stock Number5875
